Tinplate Roll

Tinplate Coil, also known as electroplated tin steel sheets, refers to cold-rolled low-carbon steel sheets or strips that are coated with commercial pure tin on both sides. Tin serves as a protective layer, preventing corrosion and rust. This material combines the strength and formability of steel with the corrosion resistance, solderability, and aesthetic appearance of tin. Tinplate Coil possesses several advantageous properties, including corrosion resistance, non-toxicity, high strength, and good ductility. It offers excellent protection against corrosion while maintaining a safe and non-toxic packaging material. Tinplate packaging has a wide range of applications in the packaging industry due to its ability to provide effective sealing, preservation, light-proofing, durability, and unique metal decoration charm.

+868615063053920

jujy@zhongwangsteel.com

E-mail

Related Products

Product message

Product Details

key word : tinplate steel coil, tin coated steel, food packaging steel, food can steel

Product Name	Tinplate(SPTE/ETP)
Standard	GB, JIS, DIN, ASTM
Material	MR SPCC
Grade	Prime
Annealing	BA/CA
Thickness	0.14-6.0mm
Width	600-1500mm
Temper	T1, T2, T3, T4, T5, DR7, DR8, DR9, TH550, TH580, TH620, TH660
Coating(g/m2)	1.1/1, 2.0/2.0, 2.8/2.8, 2.8/5.6, 5.6/5.6, 8.4/8.4, 11.2/11.2, etc
Surface Finish	Stone, Bright, Silver
Packaging	Standard export packing.or according to customer's requirements.
Payment	30% T/T or L/C

A tinplate coil is a steel plate with a thickness ranging from 0.10mm to 0.32mm, coated with a layer of pure tin on its surface. It is commonly referred to as tinplate due to its composition. There are two production methods for tinplate coils: hot plating and electroplating.

The hot plating method results in a thicker and uneven tin coating, requiring a higher amount of tin and resulting in lower efficiency. As a result, the hot plating method is gradually being phased out in favor of the more efficient electroplating method. Electroplating offers higher productivity, lower costs, and the ability to achieve thin and uniform tin coatings with controlled thickness.

In addition to standard tinplate coils, it is also possible to produce low-single tinplate coils with a tin content of 1g/m. However, these coils require pretreatment layers or post-processing layers to enhance corrosion resistance and weldability, ensuring they meet specific process requirements.

Tinplate coils find widespread use in the food industry for packaging and the manufacturing of corrosion-resistant containers. Their unique properties, such as corrosion resistance, solderability, and aesthetic appeal, make them a popular choice for preserving and protecting food products and other items.

Product Name	Tinplate
hardness	T1-DR9
Thickness	0.13-0.45mm As customer's requirement
width	600-1500mm As customer's requirement
length	As customer's requirement
Tin coating	1.1/1.1 2.0/2.0 2.8/2.8 5.6/5.6 8.4/8.4gr/㎡
Material	SPCC SPTE SPCD SPCE
advantage	Food grade corrosion resistance
Technique	Hot rolled / cold rolled
Surface Treatment	Bright finish, Stone, Silver, Matte, Gold Lacquered
Tolerance	±0.01mm
application	It is widely used in high temperature applications, medical devices, building materials, chemistry, food industry, agriculture, ship components. It also applies to food, beverage packaging, kitchen supplies, trains, aircraft, conveyor belts, vehicles, bolts, nuts, springs, and screens.
Package	tied up with steel strips and wrapped with water proof paper
MOQ	25 Tons or one container
Payment terms	L/C, T/T
Price Term	CIF, CFR, FOB, EXW
Sample	Support

Factory Appearance

Our company has 15 production lines and is capable of continuous production with a monthly inventory of tens of thousands of tons, and a total annual production of tens of millions of tons, ensuring continuous supply to customers.

Packing and shipping

The products are exported to Europe, the United States, South America, Africa, Asia, the Middle East, Australia and other countries and regions. We have our own factories and have established cooperative relations with relevant steel manufacturers to get more technical support, so that our company can perfectly meet the requirements of customers, such as TISCO, Baosteel, Li Steel, Jinsteel, Sinosteel, Jiusteel, Li Steel, Masteel, Wisco, Angang Steel and so on.

Application areas

Products are widely used in tableware, kitchenware, medical equipment, home appliances, auto parts, building decoration, petrochemical and other industries. Our company has extensive experience in the development and export of metal and steel materials. Our company is the long-term reliable steel supplier you are looking for!
